Say goodbye to costly subscriptions with FREE satellite correction services, the AG992-PRO delivers exceptional precision without breaking the bank.

• GNSS RTK plus TAP Automatic Steering System

Precision Agriculture

Precise GNSS positioning makes large-scale crop health monitoring, customized crop care, and automatic productivity management possible. Tersus GNSS positioning technology not only helps guide and schedule tractors and farm machinery, it also helps monitor crops with high resolution images from a drone, which assists crop inspection. Tersus offers a full range of GNSS options for guidance and steering.

The AG990 AutoSteer systems are designed to automate steering, reduce operator fatigue and extend working hours. The AG990 is comprised of GNSS antenna, display panel, GNSS receiver, hydraulic valve (steering wheel, optional), steering sensor, etc. An automated vehicle controller employs precise GNSS guidance information to hydraulically steer agricultural machinery. These agricultural machines automatically drive along set routes and execute planned tasks, which can be monitored on graphical displays.

TAP Service

Tersus Advanced Positioning(TAP) provides global satellite-based precise point positioning service. With TAP, AG992-Pro will not need to work with the local RTK base station or CORS but directly receives corrections broadcast by the satellites, such as ephemeris error, satellite clock error, etc.

High Precision

With TAP service, the system achieves centimeter-level high-precision positioning even in areas with poor network coverage, such as oceans, deserts, mountains, high altitudes, etc. After 10 minutes covergence time，3 cm accuracy can be achieved.

Terrain Compensation

The terrain compensation function can improve accuracy when driving straight lines across sloping or rough terrains with minimized skips and overlaps.

Easy Installation & Debugging

AG992 system adopts a modular design, which is easy to install and use. Users can install and debug by themselves according to the guidance, and the transfer operation between different vehicles is also more convenient.

Multiple Working Modes

The system supports multiple operating modes: straight line, curve, A plus navigation line, 90° straight line, circular curve, etc., to complete various complex operations.

Multiple Application Scenarios

Improved agricultural efficiency and productivity in different scenarios: Ridging, Sowing, Transplant, Trenching, Spraying, Harvesting, etc.

Features:

• Supports multiple constellations and frequencies:

-GPS L1 C/A,L2C,L2P,L5

-GLONASS L1 C/A,L2 C/A

-BeiDou B1,B2, B3,support BDS-3

-Galileo E1, E5a, E5b

-QZSS L1C/A,L2C,L5

-SBAS supports WAAS,EGNOS,GAGAN,SDCM,MSAS

-L-band

• Satellite-based PPP service (Tersus TAP)
• Small high-torque motor Highly integrated system
• 10.1" touch screen control tablet
• Auto-Steering error less than 2.5cm
• Without modification of the hydraulic system
• Simple & Fast installation
• Easy & Quick calibration procedures
• AG992-Pro has been tested for CE & FCC regulations.
