The Case IH Farmall JX Series is engineered to deliver exceptional performance in demanding agricultural applications. With models ranging from 70 to 110 horsepower, these tractors are built to handle a variety of tasks with ease and efficiency.

Whether you're cultivating fields, handling heavy-duty implements, or maneuvering in tight spaces, the Farmall JX offers the power and versatility needed to get the job done effectively.

From its robust transmission options and high-capacity hydraulics to its ergonomic design and advanced technology, the Farmall JX is designed to meet the diverse needs of modern farming operations.

This isn't just a tractor.

It's the Case IH Farmall JX.

Key Features

Engine & Performance

• Engine Type: Turbocharged and intercooled, mechanical injection Tier 3 engines.
• Power Output: Ranges from 70 to 110 horsepower, providing reliable power for various tasks.
• Fuel Efficiency: Designed for optimum fuel efficiency and maximum power output.

Transmission Options

• 12x12 Synchromesh: Standard transmission offering smooth gear shifts.
• 12x12 Powershuttle: Optional hydraulic powershuttle for easy forward/reverse maneuvering, especially during loader work.
• 20x12 Creeper Speed: Available for tasks requiring low-speed operations.

Hydraulics & PTO

• Hydraulic System: High-capacity open-centre systems with options up to 63 l/min, supporting up to three rear remote valves.
• PTO Options: Standard 540 rpm PTO with optional 540/540E or 540/1000 rpm configurations.
• Rear Linkage Lift Capacity: Up to 4,700 kg at ball ends.

Cab & Operator Comfort

• Cab Design: Ergonomically designed cab with wide-opening, solid glass doors and anti-slip steps for easy access.
• Visibility: Slim pillars and large mirrors provide excellent all-round visibility.
• Comfort Features: Reduced cabin noise levels and logically positioned controls for ease of operation.

Additional Features

• High-Visibility Roof Screen: Optional for enhanced visibility during loader work.
• Lighting Package: New worklights integrated into the roof, adjustable for optimal illumination.
• Safety: Optional braked front axle for additional assurance when stopping under various conditions.
